Multi-function Hinge Drilling Jig Woodworking Tool Drill

Features:Versatile Use --- This tool kit is suitable for hinge punching positioning vertical punching panel dowel punching side panle line drawing.Accurate and Reliable --- Repeatable results with measuring scales; reliable drilling with bit guide. The hole jig is a great tool set for both furniture factory and woodworking enthusiasts.Well Accessoried --- 5-10mm drill bushings and drill guide body are fixed by screws more stable and with strong clamping force when drilling. 5 bushings easy to exchange for different drill needs.Superior Quality --- Drill guide body use the newest engineering plastics wear-resistant and longevity; drill bushings made from abrasive cast steel with high hardness and corrosion resistance.Drilling Helper --- The Concealed Hinge Jig allows you to drill cup holes for concealed cabinet door hinges.Instructions:1. Hinge punching: This punch is suitable for 35mm hinges and supports 46mm 48mm 52mm hinge cup screw holes.2. Vertical punching: Remove the bottom positioning screw draw a cross line at the position where you need to punch and use the drill bit to align the intersection to complete the hole punching.3. Draw the center line on the side of the board: Install the positioning screw on the centering screw hole use the drill sleeve matched with the refill. If there is an error in the size of refill and the drill sleeve a small amount of tape can be wrapped around the refill.4. Board splicing dowel punching: Align the two plates that need to be assembled draw a straight line on the side install the positioning screw on the screw hole in the center line of the hole punch. The edge of the punch is aligned with the line and rotale the punch to make the positioning screw close.Specifications:Material: Aluminum AlloyPackage Size: 21*12.4*6.8cm / 8.3*4.9*2.7inPackage Weight: 633g/22.32ozPackage List:2 * Copper sleeve (11mm 12mm)1 * 35mm hole opener4 * Drill sleeve (5mm 6mm 8mm 10mm)1 * Positioning screw1 * 2mm drill bit1 * Allen wrench1 * Main boby
