RX-40QZ Wired PIR Motion Detector Passive Infrared Movement Sensor for Home Alarm

The RX Series gives extremely high false alarm protection with excellent tolerance to spot temperature changes from curtains and small animals. Using patented Quad Zone Logic, it is able to accurately discriminate between humans and other sources of infrared, providing reliable detection in a diverse range of applications.

Feature:

1) Patented Quad Zone Logic

2) Spherical lens design

3) Temperature Compensation

4) Sealed Optics

5) Selectable pulse count: 2 or 4

6) 100% factory tested for reliability

SPECIFICATIONS:

1) Detection Method: Passive Infrared

2) Coverage: 40ftx40ft (12mx12m), 85degree

3) Detection zones: WIDE 78 zones

4) Mounting height: 5-8ft (1.5-2.4m)

5) Sensitivity: 0.6m/sec (3.6F at 2ft/sec)

6) Detection Speed: 1 to 5ft/sec (0.3-1.5m/sec)

7) LED alarm indicator: Switch-able ON/OFF

8) Alarm Period: Approx 2.5 sec

9) Alarm Output: N.C 28VDC 0.2A Max

10) Tamper Switch: N.C, open when cover is removed

11) Pulse count: Approx 20sec 2 or 4

12) Warm Up Period: 30 sec

13) Power input: 9.5-16VDC (NOT included)

14) Current draw: 8mA(normal), 11mA(Max) at 12VDC

15) Operating Temperature: -4F--122F (-20--+50degree)

16) Environmental humidity: <95%

17) RF interference: No alarm 20v/m

Packeg Include

1 x RX-40QZ Wired PIR motion detector (NOT include bracket)

1 x English user manual
