315MHZ 4 Buttons Remote Controller with Base 4 Power Switch Widely Use

Description:

Widely Use: Garage doors, cars, motorsycles and other wireless remote control
Frequency: 315MHz
Buttons: 4 buttons

Working: jogging, self-locking ,interlocking.

Suitable for ( about 20 codes): fixed code- chip of PT2262、SC2260 ; code of remote control - EV1527、HS2240 ect.

Specification:

Working voltage: AC180－240V

Maxium: 1500W

Code learning: Press the learning button for three second, indicator light off. Then press any button on the remote control, the indicator light will from flash 4 times to lingt ever light which learning successfully.

Code clearing: Press the learning button for eight seconds untill the light on which shows it clearing successfully.

Size Chart:

Pcb Size: Approx. 54.4×31.7×17mm/ 2.15×1.25×0.67 inch

Case size: Approx. 74×36×23 mm/2.91×1.41×0.91 inch

Package Includes:

4 Pieces Power Switch

1 Piece Remote Control
