AC85~250V 1CH 433MHz Wireless Remote Control SwitchS Module For Garage Door

Description:

Four 10A relays used to load high-power appliances; 3 output modes of inching (start-stop), self-locking, interlocking; has closed output port for special applications

Mainly used in lamps, garages, electric doors, windows, lifting equipment, motor control, water pumps, gateways, lifts, industrial control and security industries

Wide voltage range, 85-250 volts; High voltage isolation and safe low voltage part

Static power consumption is very low( 10 mA); RC is generally above 40

Can learn 16 fixed codes, come with detailed instructions and circuit diagrams for customer's convenience

Specification:

Working voltage: DC15-120V

Standby working current: 10mA

Working frequency: 433MHZ

Working mode: inching (start-stop), self-locking, interlocking (adjustable)

Maximum load: 1000 watts / way

Enclosure size: 98 x 44 x 27.5mm/3.86x1.73x1.08inch

PCB size; 38 x 67 x 16.5 mm/1.50x2.64x0.65inch

Press and hold the learning button for 3 seconds, the indicator light will automatically go out. Then release the learning button, press any button on the remote control, the indicator light flashes for 4 times, indicating that the learning is successful.
Note: This controller can learn 20 fixed codes of different codes and arbitrary buttons. If it exceeds 16 codes, it will clear the earliest learned fixed code.
How to clear the learning code:
Press and hold the learning button for about 4 seconds. The indicator will turn off and return to be on,indicating that the sweeping is successful.

Package Includes:

1 Piece Switch
