Development RF Signal Source Phase Locking Loop Board Domain Analysis Tool ADF4350

Description:

RF signal source frequency synthesizer development board.
The circuit board layout design is meticulous and ingenious.
Multifunction: basic functions such as point frequency, frequency sweep, frequency hopping.
Convenient and simple operation.
Made of quality plastic, durable for use.

Specification:

Output frequency range: 137-4.4GHz(ADF4350) ,35MHz - 4.4GHz(ADF4351)
Supply voltage: 4-9V (5VDC)
Output signal:
2.2GHZ--4.4GHz sine wave (fundamental)
35MHZ--2.2GHz squarewave (fundamental division)
Output signal: output speed, signal strength: + 5dBm (programmable)
RF connector: SMA female head
Control Interface: Three-wire Serial Peripheral Interface Bus
Reference Clock: 10.000MHZ (default), through the interface to an external SMA
Size: Approx. 4.8 x 4.9cm / 1.89 x 1.93inch
Weight:15g

Size Chart:

Size: 50x50mm/1.96x1.96inch

Package Includes:

1 Piece RF Signal Source Frequency Synthesizer

Note:

Color might be slightly different due to the color calibration of each individual monitor.
Please allow slightly measuring deviation due to manual measurement.
