DSO138 Hand Held Oscilloscope Charger Adapter Power Supply DIY Parts 1Msps

Description:

Input voltage: 100-240VAC 50/60HZ
Output voltage: 9V 1A
Highest Real-time sampling rate: 1Msps
Accuracy: 12 Bit
Sample Buffer Depth: 1024 Bytes

Specification:

Material: Plastic + Electronic Components
Product detailed size: The length is about 87cm/34.25inch,the plug is about 75 x 30 x 45mm/ 2.95 x 1.18 x 1.77inch
Analog Bandwidth: 0 - 200KHz
Vertical sensitivity: 10mV/Div – 5V/Div (in 1-2-5 increments) Adjustable vertical displacement with indication
Input impedance: 1MΩ
The highest input voltage: 50Vpp (1:1 probe), 400Vpp (10:1 probe)
Coupling methods include DC/AC/GND
Horizontal time base range: 10μs/Div – 50s/Div (in 1-2-5 increments) With automatic, regular, and single-shot triggering, it is easy to capture momentary waveforms. Triggered rise or fall triggers the position of the level. With instructions to observe the waveform before triggering (negative delay) The waveform display can be frozen at any time (HOLD function) Built-in 1KHz/3.3V square wave test signal source with digital display of waveform parameters, the displayable parameters are: frequency, period, Pulse width, duty cycle, maximum value, minimum value, average value, peak-to-peak value, rms save/recall waveform, shutdown waveform does not disappear
To turn on/off the waveform parameter display: Position the cursor on the time base and press and hold the [OK] key.
How to save the waveform: Press the [SEL] and [+] keys at the same time.
To recall a saved waveform: Press the [SEL] and [-] keys simultaneously.
To enter the test mode: Press and hold [OK] and press the [RESET] key. If you see that the LED flashes quickly, it means that there is a short circuit between the PB or PC ports of the microcontroller (these ports include the connection to the LCD). Removed after exit; if you see the LED blinking for a period of about 4 seconds, you can use a voltmeter to find possible open circuits in the connection lines with the microcontroller port.

Package Includes:

1 Piece DSO138 Oscilloscope dedicated power supply.

Note:

Please allow 1-3mm error due to manual measurement.
Please make sure you do not mind before you bid.
Photo color might be a little different from the actual product due to color display of different monitors.
Thanks for your understanding and enjoy your shopping moment.
