Metal Tracked Robot Smart Car Platform Chassis 12V for Robot Project

Description:

All Metal Tracked Robot Smart Car Platform Chassis for Robot Project
Aluminum alloy Frame allows the car tires to always be perpendicular to the ground 90 degrees, allowing any environment, smart cars can easily overcome obstacles.
Designed for both beginners and professionals to learn robotics. Very intuitive and simple regardless of whether you are an engineer or a novice.
Building up your own robotic project has never been so easy and fun.
This kit enables you to have a good quality time with your children and empower them to develop and inspire their imaginations.

Specification:

Name: Mini T100 Tracked Tank Chassis
Material: Aluminum Alloy
Surface treatment: sandblasting oxidation
Color: Golden yellow、silver、black (for optional)
Track: Zinc Alloy
Size: About 207*185*58mm(Length*width*Height)
Weight: about 1.15kg
Design load: 5kg

Motor parameters:
Name: 25mm gear motor
RPM: 350±10%rpm
No_load Current: 200mA (Max)
Stall current: 4500mA(max)
Stall torque: 9.5kgNaN
Rated speed: 100±10%rpm
Rated torque: 3000gNaN
Rated Current: 1200mA (Max)
Noise: 56dB
Working voltage: 12V
Outside Shaft Length: 14.5mm
Shaft End Play: 0.05-0.50mm
Screw Size: M3.0
Dia. Of Shaft phi4mm, D3.5
Encoder: 2 pulses/circle

Package Includes:

1 Set Mini T100 Tracked Tank Chassis
2 Piece 12V Motors

Note:

The tank chassis is unassembled for the transpotation convenient, please contact us to get the installation manual or visit our official wiki: wiki.doit.am.
