Intuitive LCD display that can clearly indicate the status and data is able to switch modes and parameter configuration
3-Phase charge management, effectively protects the battery, and the battery is more durable
Built-in overcurrent, short circuit, reverse connection, and open circuit protection, all automatic recovery
4-Way USB output, 2A maximum current, supporting charging for your phone, tablet PC, etc.
Suitable for lead-acid batteries (12V/24V automatic adaptation), lithium batteries, and lithium iron phosphate batteries
Specification:
System voltage: 12V/24V (adaptive) (12V battery is suitable for 18V photovoltaic panel, and 24V battery is suitable for 36V photovoltaic panel)
Rated charging current: 30A/40A/50A/60A/100A
Rated discharge current: 10A/20A/20A/30A/30A
Maximum photovoltaic voltage: 23V for 12V batteries and 46V for 24V batteries
Charging cut-off voltage value:
B1: Lead acid battery (14.2V)
B2: Ternary lithium battery (12.2V)
B3: Lithium iron phosphate battery (14.6V)
Floating charging voltage: 14.2 V (default, adjustable)
Discharge cut-off voltage: 10.7 V (default, adjustable)
Discharge recovery voltage: 12.6 V (default, adjustable)
Standby current: <10mA
Working temperature: - 35-60?
4-Way USB output: Max. 5V/2A
